Maximum power dissipation for nominal condition |
16.44 W (US = 26.4 V, IL² = 72 A², PTotal max = 2.04 W + 14.4 W) |
Nominal operating mode |
100% operating factor |
Rated insulation voltage |
250 V |
Rated surge voltage/insulation |
See data sheet, section “Insulation coordination”. |
Supply |
Rated control circuit supply voltage US |
24 V DC -15 % / +10 % |
Rated control supply current IS |
typ. 70 mA (at US) |
Power consumption at US |
typ. 1.68 W |
Inrush current |
< 3.5 A (typ. with US, Δt = 3 ms) |
Filter time |
5 ms (in the event of voltage dips at Us) |
Protective circuit |
Serial protection against polarity reversal; Suppressor diode |
