PRK5/4P-200-M12, LEUZE, Sensor, fotoeléctrico retrorreflectivo polarizado, 0.02 … 4.5 m, Led, 10-30VDC
Description
| Series | 5 |
| Operating principle | Reflection principle |
| Operating range | 0.02 … 4.5 m (guaranteed operating range), With reflector TK(S) 100×100 |
| Operating range limit | 0.02 … 6 m (typical operating range), With reflector TK(S) 100×100 |
| Light source | LED, Red |
| Wavelength | 620 nm |
| Transmitted-signal shape | Pulsed |
| LED group | Exempt group (in acc. with EN 62471) |
| Protective circuit | Polarity reversal protection Short circuit protected |
| Supply voltage UB | 10 … 30 V, DC, Incl. residual ripple |
| Residual ripple | 0 … 15 %, From UB |
| Open-circuit current | 0 … 20 mA |
| Number of digital switching outputs | 2 Piece(s) |
| Type | Digital switching output |
| Switching element | Transistor, PNP |
| Switching principle | Light switching |
| Switching element | Transistor, PNP |
| Switching principle | Dark switching |
Mas Información?
Additional information
| Weight | 0,040 kg |
|---|---|
| Dimensions | 20,2 × 14,0 × 32,5 cm |
