Secificaciones

Type of safety according to IEC 61496-1 3

Maximum safety range 3 m

Maximum warning range 10 m

Cable entry direction Side

Type of switching output of the OSSD PNP

Connection method Pigtail connector

Key features Configurable object resolution of 30, 40, 50 or 70 mm, Manual/auto start, Reference boundary monitoring

Type of protection Hand protection

Detection capability 70 mm

Suitable for safety functions

Scan angle 270 °

Scanning interval 0.4 Hz

Response time 80 ms

Number of safety fields 140

Wavelength of the sensor 905 nm

Number of protected semiconductor outputs 2

Number of semiconductor outputs with signalling function 2

Laser protection class Class 1

Supply voltage DC 16.8-30 V

Voltage type DC

Max. output current at protected output 250 mA

Degree of protection (IP) IP65

With alert field output

Ambient temperature -10-50 °C

Overall length of sensor 143 mm

Height of sensor 105 mm

Width of sensor 105 mm

OS32C-BP OS32C with back
location cable entry
4 m OS32C-BP-4M
3 m OS32C-SP1
CD-ROM (Configuration tool)
OS supported:
– Windows 2000,
– Windows XP (32-bit version,
Service Pack 3 or later)
– Windows Vista (32-bit version),
– Windows 7 (32-bit version/64-bit version)

4 m OS32C-SP1-4M
3 m OS32C-BP-DM
OS32C with Ether-Net/IP and back lo-cation cable entry, 4 m OS32C-BP-DM-4M, 3 m OS32C-SP1-DM, OS32C with Ether-Net/IP and side location cable entry*1
4 m OS32C-SP1-DM-4M
