MFDHT5440, PANASONIC, MINAS A5, SERVO, control de posición, velocidad y par, con función de desconexión de par de seguridad (STO), 3 kW, 3 x 400 V CA
Description
DETALLES:
| Item | Specifications |
|---|---|
| Part Number | MFDHT5440 |
| Product details | A5 series Speed, Position, Torque, Full-closed type with the safety function |
| Family Name | MINAS A5 |
| Series | A5 series |
| Type | Speed, Position, Torque, Full-closed type |
| Frame | F-Frame |
| Frequency response (kHz) | 2.3 |
| Control method | Position control, Velocity control, Torque control, and Full-closed control |
| Safety Function | with |
| Power device Max. current rating | 50A |
| Current detector current rating | 40A |
| Supply voltage | 3-phase 400 V |
| I/F Classification of type | Analog/Pulse |
| Dimensions (W) (Unit: mm) | 130 |
| Dimensions (H) (Unit: mm) | 220 |
| Dimensions (D) (Unit: mm) | 214 |
| Mass (kg) | 5.2 |
| Environment | For more details, please refer to the instruction manual. |
Mas Información?
Contáctenos..
Additional information
| Weight | 5,2 kg |
|---|
