M200-044 00135A, Emerson Drive, Unidrive, Control Technique, 3 phase 380-480V 5,5kW

Description

Emerson Drive.

Add to Comparison

Technical Specification

Manufacturer: Emerson

Series: Unidrive M200

Model: M200-044 00135A

Application: general purpose

Capacity, kW: 5,5

Current, А: 13.5

Main power supply, V: 380-480

Phase: 3

Output frequency, Hz: 0-550

Enclosure: IP21 / UL open class (NEMA 1). IP20 when the AI Adaptors are fitted

Overload capacity, % per 1 min.: 150

EMC filter: +

Braking unit: optional

Analog input: 2

Digital input: 4

Analog output: 1

Digital output: 1

Relay output: 1

PID: –

V/f control mode: +

Vector control with feedback: –

Sensorless vector control: –

Operation temperature, °С: -20…..+40

Storage temperature, °С: -40…..+60

Dimensions (W x H x D), mm: 115x245x175

Weight, kg: 13,3

Mas Información?

Additional information

Weight	13,3 kg
Dimensions	17,5 × 11,5 × 24,5 cm
