DH-220, KEYENCE, 2 head type (Sensor head), Argentina, proveedor
Description
Especificaciones:
| Model | DH-220 | |||
| Type | 2 head type (Sensor head) | |||
| Amplifier unit | DD-860 | |||
| Shape | Standard | |||
| Detection method | Detection with a target between the transmitter and the receiver | |||
| Plate thickness | [T/R separation : 30 mm 1.18″ max.] Steel *1 : 0.04 mm to 4.5 mm 0.002″to 0.18″ Aluminum : 0.02 mm to 10 mm0.001″ to 0.39″ Copper : 0.01 mm to 5.0 mm0.0004″ to 0.20″ Brass : 0.03 mm to 5.0 mm0.001″ to 0.20″ Stainless steel : 0.1 mm to 5.0 mm0.004″ to 0.20″ |
|||
| Maximum separation | 30 mm 1.18″ | |||
| Allowable vibration | 30 mm 1.18″ max. (100 x 100 mm 3.94″ t=3.2 mm 0.13″ max.) |
|||
| Minimum detectable object | 50 x 50 mm 1.97″ (T-to-R distance: 30 mm 1.18″ Vibration: ±4 mm ±0.16″) |
|||
| Output | Control output 1 |
NPN: 100 mA (40 V) max., Residual voltage: 1 V max.*1 | ||
| Control output 2 |
Relay output SPDT: 250 VAC, 2 A (resistive load)*1 | |||
| Response time | 50 ms (selectable: 5 ms) | |||
| Rating | Power voltage | 115/230 VAC ±15 %, 50/60 Hz | ||
| Power consumption | 10 VAC max. | |||
| Environmental resistance | Ambient temperature | -10 to +60 °C 14 to 140 °F | ||
| Relative humidity | 35 to 85 % RH (No condensation) | |||
| Vibration resistance | 10 to 55 Hz, Double amplitude 1.5 mm 0.06″, 2 hours in each of the X, Y, and Z directions | |||
| Weight | Approx. 300 g | |||
Mas Information? Keyence Argentina, Asistencia técnica
Additional information
| Weight | 0,300 kg |
|---|---|
| Dimensions | 4,5 × 3,0 × 3,0 cm |
