AMMS 10-44/1, Murrelektronik, Módulo, Opto-Acoplador, IN: 53 VDC – OUT: 53 VDC / 1,2 A
Description
Description
Transistor 1.2 A
24 V DC
24 V DC
HEADER
| Material short text | AMMS 10-44/1 |
|---|
ELECTRICAL DATA | INPUT
| Input voltage DC min. | 10 V |
|---|---|
| Input voltage DC max. | 53 V |
| Input voltage OFF DC min. | 0 V |
| Input voltage OFF DC max. | 3 V |
| Input current | 6 mA |
ELECTRICAL DATA | OUTPUT
| Voltage drop DC max. | 12 V |
|---|---|
| Quiescent current OFF max. | 0.3 mA |
| Switch on delay max. | 100 µs |
| Switch off delay max. | 700 µs |
| Voltage switching DC min. | 45 V |
| Switching voltage DC max. | 53 V |
| Switching current min. | 1 mA |
| Switching current max. | 12 A |
| Switching frequency ohmic max. | 500 Hz |
| Switching frequency inductive max. | 30 Hz |
DIAGNOSTICS
| Status indication LED | red |
|---|
DEVICE PROTECTION | ELECTRICAL
| Rated insulation voltage | 3,750 V |
|---|
DEVICE PROTECTION | MEDIA
| Flame resistance | flame retardant |
|---|
MECHANICAL DATA | MATERIAL DATA
| Material housing | Plastic |
|---|---|
| Color housing | black |
MECHANICAL DATA | MOUNTING DATA
| Height | 56 mm |
|---|---|
| Width | 12 mm |
| Depth | 64 mm |
| Mounting method | geschnappt |
| Suitable for mounting type | Mounting rail TH35, (EN 60715), G32 |
ENVIRONMENTAL CHARACTERISTICS | CLIMATIC
| Operating temperature min. | -20 °C |
|---|---|
| Operating temperature max. | 60 °C |
Mas Información? Murrelektronik, Argentina, Proveedor, Industrial
Additional information
| Weight | 0,028 kg |
|---|---|
| Dimensions | 6,4 × 1,2 × 5,6 cm |
