1794-OE12, Allen Bradley, FLEX I/O 12AO CURRENT SINGLE ENDED MODULE.
Description
El Allen-Bradley 1794-OE12 es un módulo de salida analógica Flex IO. Este módulo presenta doce (12) canales de salida analógica de voltaje/ corriente sin aislados de un solo salto. Ofrece señales de corriente de salida como 4-20 mA, 0-20 mA y señales de voltaje, como ± 10VDC. Es compatible con bases terminales como 1794-TB3G o 1794-TB3GS. Es compatible con los adaptadores Flex IO de 1794 para implementar la aplicación de E/S distribuida.
Technical specifications for 1794-OE12
| Manufacturer | Rockwell Automation |
|---|---|
| Flexbus Current | 80 mA |
| Part Number/Catalog No. | 1794-OE12 |
| Brand | Allen-Bradley |
| Product Description: | Flex IO High Density Analog Output Module |
| No. of outputs: | Twelve (12) Single Ended |
| Output type: | 0 to 20 mA; 4 to 20 mA; +/- 10VDC; |
| Conversion Type: | Digital to Analog Converter |
| Resolution: | 16 bit 2’s complement, left justified |
| Terminal base: | 1794-TB3G; 1794-TB3GS |
| Indicators: | 1 green/red power/status indicator |
| External DC supply, nom: | 24V DC |
| External DC supply range: | 10.0…31.2V DC (includes 5% AC ripple) |
| Mounting: | DIN Rail |
| Wire Size: | Determined by installed terminal base |
| Operating Temperature: | 0 to 55 C (32 to 131 F) |
| Storage Temperature: | –40…85 °C (–40…185 °F) |
| Vibration: | 5g @ 10 to 500 Hz |
| Operating Shock: | 30 g |
| Product Type | Flex I/O Analog Output Module |
| Outputs | 12 Single-ended |
| Output Voltage Range | +/-10V |
| Output Current | 0-20mA max. |
| Voltage Output Current Load | 3mA max. |
| Voltage Resolution | 320 ?V/cnt |
| Current Resolution | 0.641 ?A/cnt |
| Resistive Load, mA Output | 0750 ? @ 24V DC |
| Power Dissipation | 4.0W @ 31.2V DC |
| Thermal Dissipation | 4.7 BTU/hr. @ 24V DC |
| UPC | 10612598320193 |
Manual Usuario Flex I/O Allen Bradley, proveedor, Argentina.
FLEX I/O High-Density Analog Modules
Catalog Numbers: 1794-IE8, 1794-IE8XT, 1794-OE4, 1794-OE4XT, 1794-IE12, 1794-OE12, 1794-IE4XOE2, 1794- IE4XOE2XT, 1794-IE8XOE4
Mas información?
>>>1794-um062
