Short Circuit Current Ratings for 100-C12D10

Operational Rating Dual Element Time Delay Fuses Circuit Breakers Rating Reference File Ref: UL File Ref: CSA Comments

SCCR [kA] Max Fuse Size [A] Fuse Class CB Type UL CMC Type Catalog Numbers SCCR [kA] SCCR [kA] SCCR [kA] SCCR [kA]

600V 480V 480Y/277V 600V 600Y/347V

12A (AC3/4)10020CC, JUL 508 Manual Motor Controller–140M-C2E-A16 to 140M-C2E-B1665–47–Instruction SheetE3125cULus

12A (AC3/4)540K5, RK5UL 508 Manual Motor Controller–140M-C2E-B25 to 140M-C2E-C1065–30–Instruction SheetE3125cULus

12A (AC3/4)——UL 508 Manual Motor Controller–140M-C2E-C1630–30–Instruction SheetE3125cULus

12A (AC3/4)——UL 508 Manual Motor Controller–140M-D8E-B25 to 140M-D8E-C1665–30Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Self Protected» Manual CMCE (2 Comp)140M-C2E-A16 to 140M-C2E-B16–65–47Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Self Protected» Manual CMCE (2 Comp)140M-C2E-B25–65—-Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Self Protected» Manual CMCE (2 Comp)140M-D8E-B2565—-Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Self Protected» Manual CMCF (2 Comp)140M-C2E-A16 to 140M-C2E-B16–65–47Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Self Protected» Manual CMCF (2 Comp)140M-C2E-B25 to 140M-C2E-B40–65–30Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Self Protected» Manual CMCF (2 Comp)140M-C2E-B63 to 140M-C2E-C10–65—-Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Self Protected» Manual CMCF (2 Comp)140M-C2E-C16–30—-Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Self Protected» Manual CMCF (2 Comp)140M-D8E-B25 to 140M-D8E-C16–65–30Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Mag Only» Manual Motor Controller–140M-C2N-A40 to 140M-C2N-B1065–47–Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Mag Only» Manual Motor Controller–140M-C2N-B16 to 140M-C2N-B2565–30–Instruction SheetE3125cULus

12A (AC3/4)——UL 508 «Mag Only» Manual Motor Controller–140M-D8N-B25 to 140M-D8N-C1665–30–Instruction SheetE3125cULus

12A (AC3/4) — — — UL 508 «Mag Only» Manual Motor Controller E (3 Comp) 140M-C2N-A40 to 140M-C2N-B16 — 65 — 47 Instruction Sheet E3125 cULus Requires 193-E Overload Relay

12A (AC3/4) — — — UL 508 «Mag Only» Manual Motor Controller E (3 Comp) 140M-C2N-B25 — 65 — — Instruction Sheet E3125 cULus Requires 193-E Overload Relay

12A (AC3/4) — — — UL 508 «Mag Only» Manual Motor Controller E (3 Comp) 140M-D8N-B25 — 65 — — Instruction Sheet E3125 cULus Requires 193-E Overload Relay

12A (AC3/4) — — — UL 489 MCCB C 140U-D6D*-C30 — 65 — 25 Instruction Sheet E3125 cULus Requires 193-E Overload Relay

12A (AC3/4) — — — UL 489 MCCB C 140U-H*C3-C30 5 5 — — Instruction Sheet E3125 cULus Requires 193-E Overload Relay

12A (AC3/4)——UL 489 MCPD—————-
